Imperial IR-4-G24 48″ Propane Gas Range With 24" Griddle

SKU: SKU: IR-4-G24-L

Product Description



• Open burners – PyroCentric™ 32,000 BTU (9 KW) anti-clogging burner with a 7,000 BTU/hr. (2 KW) low simmer feature. Two rings of flame for even heating.
• Cast iron PyroCentric burners are standard on all IR Series Ranges.
• Burners are anti-clogging and lift-off and separate for easy cleaning. No gaskets or screws.
• One standing pilot per burner for instant ignition.
• Grates – Front grates measure 12″ x 11″ (305 x 279 mm). Back grates are 12″ x 13″ (305 x 330 mm).
• Back grates are sized for positioning large stock pots directly over burner and feature a hot air dam.
• Pots slide easily from section to section and onto landing ledge.
• Grates are cast iron for a long service life.
• Griddle – Highly polished 3/4″ (19 mm) steel plate. 21″ (533 mm) plate depth.
• Burners have 20,000 (6 KW) BTU/hr. output with a heat deflector every 12″ (305) for even heating.
• 3″ (76 mm) wide grease trough and removable grease can for easy cleaning.
• Large griddle grease can and full width broiler drip tray are removable for easy cleaning.
• Standard space save oven – Both Space Saver and Chef Depth ovens are available.
• Linear burner provides even heating throughout the oven.
• Space Saver output is 27,000 BTU (8KW), Chef Depth is 35,000 BTU (10 KW).
• Unique burner baffle distributes heat flow to provide even temperatures throughout the oven cavity.
• Exclusive heat deflector reflects heat into the oven, not the floor. 100% safety pilot.
• Space Saver interior is 20″ w x 26″ d x 14″ h (508 w x 660 d x 356 h mm). Chef Depth interior is 26-1/2″ w x 26″ d x 14″ h (673 w x 660 d x 356 h mm) and accommodates 18″ x 26″ (457 x 660 mm) sheet pans left-to-right and front-to-back.
• Porcelainized sides, rear, deck and door lining for easy cleaning. Heavy duty door hinge.
• Stamped inner door liner provides extra strength while optimizing heat retention.
• One chrome oven rack included
• Convection Oven – 30,000 BTU/hr. (9 KW) convection oven with 1/4 hp blower motor cooks products quickly and evenly with less shrinkage.
• Convection oven interior dimensions 26-1/2″ w x 22-1/2″ d x 14″ h (673 x 572 x 356 mm).
• Three position switch for cooking or cool down. Fan shuts off automatically when door is open.
• Porcelainized sides, rear, deck and door lining for easy cleaning. Heavy duty door hinge.
• Three chrome oven racks included.
